BL14 series(Equal B3-014) Copper Brazed Plate Heat Exchanger Freon Water

BL14 series(Equal B3-014) Copper Brazed Plate Heat Exchanger Freon Water

Air conditioning /Refrigeration
Brazed plate heat exchanger is most common used in Air condition, for example Evaporator, condenser.

Working Principle

Brazing the stainless steel plates together eliminates the need for sealing gaskets and thick frame plates. As well as holding

the plates together at the contact points, the brazing material seals the package. Baode's brazed heat exchangers are brazed

at all contact points, ensuring optimal heat transfer efficiency and pressure resistance. The plates are designed to achieve

longest possible lifetimes. Since virtually all material is used for heat transfer, the Brazed Plate Heat Exchanger is very compact

in size and has a low weight and a low hold-up volume. The BPHE (Brazed Plate Heat Exchanger ) consists of thin corrugated

stainless steel plates which are vacuum brazed together using copper as the brazing material. Copper brazed units can be used for numerous of applications. For food applications and applications involving aggressive fluids, Nickel brazed units are requested.

Standard design
The plate pack is covered by cover plates. Connections are located in the front or rear cover plate. The channel plates are corrugated to improve heat transfer efficiency and to make them rigid.

Standard materials
Cover plates: Stainless steel AISI 316
Connections: Stainless steel AISI 316
Plates: Stainless steel AISI 316
Brazing material: Copper

Particulars required for quotation
To enable Baode's representative to make a specific quotation, enquiries should be accompanied by the following particulars:
– flow rates or heat load required
– temperature program
– physical properties of liquids in question
– desired working pressure
– maximum permitted pressure drop

Advantages of brazed plate heat exchangers in Industry and HVAC&R
The Baode Brazed plate heat exchangers (BHE) have several advantages over traditional heat exchangers in Industrial and HVAC&R applications.
– The high heat transfer efficiency of the BHE makes it extremely compact and also easy to install in places where space is limited.
– The unit has no gaskets and is therefore suitable in applications where temperature and/or pressure is high e.g. in district heating.
– The Baode supply system reassures that, no matter where you are on the globe, the BHE units are available with a very short delivery time.
